198
Chapter 7 Installing Internal Options
■ How to Remove the Internal Hard Disk Unit
1 Turn off the server and all peripheral devices. Also unplug all power cables from
the server.
"1.4.3 Turning Off the Server" (pg.33)
2 Touch a metal part of the server to discharge static electricity.
3 Remove the internal hard disk unit.
Pressing the tab on the front of the internal hard disk unit, hold up the handle (1), and pull it
forward (2). Hold the internal hard disk unit with both hands to pull it out.
4 Install a new internal hard disk unit or a dummy unit.
"7.6.3 How to Install the Internal Hard Disk Unit" (pg.197)
Tab
1
Handle
2
To Next Page
