PRIMERGY RX100 S3 User’s Guide
1
Overview
d LAN connector B ( )
This is a PCI port. The applicable cable and meanings of the LEDs are the same as those for LAN
connector A.
e Serial port (9 pin) ( )
Cables of peripheral devices conforming to the RS-232C standard such as modems are plugged
in.
f Display connector (15 pin) ( )
A display cable is plugged in.
g Mouse connector (6 pin) ( )
A mouse is plugged in.
h Keyboard connector (6 pin) ( )
A keyboard is plugged in.
i Rear maintenance LED ( )
When the server is not turned on (standby mode), this LED is lit in amber.
When the server is turned on and ServerView has been installed, this LED is lit in amber during
onboard SCSI array controller logical drive initialization/rebuilding.
This LED lights or blinks in amber when the server is turned on and an error is detected in the
server components.
If this LED lights or blinks other than drive initialization/rebuilding, contact an office listed in the
"Contact Information" of "Start Guide".
j System identification LED ( )
This LED is used for maintenance. When pressing this button, the front and rear system
identification LEDs are lit blue so that the locations of devices being maintained can be
determined. Also, the "System Identification LED Display" button of ServerView can be used to
light them.
ID
