50 Service Supplement TX100 S2
Replacement routines
Figure 29: Reconnecting the front panel cable to the front bezel
Ê Carefully snap the On / Off button and both LED indicators on the new front
panel cable into the front bezel.
1 black / blue
On / Off button
2 black / green Power-on indicator
3 black / red HDD activity indicator
