Fujitsu PRIMERGY TX150 S6

100 Operating Manual TX150 S6
Hot-plug components CSS components
8.1.2.4 Unlocking the HDD module
Unlocking the 3.5-inch HDD module
I If HDD modules are provided with a transport lock, remove the lock
before releasing the locking mechanism.
Figure 34: Removing the transport lock
Ê Pull the transport lock out in the direction of the arrow.
Figure 35: Unlocking the HDD module
Ê Release the locking mechanism by pressing the locking button (1).
Ê Push the handle of the HDD module fully in the direction of the arrow (2).
The HDD module is now unlocked.
1
2
