Fujitsu PRIMERGY TX150 S6

TX150 S6 Operating Manual 113
CSS components Non-hot-plug components
8.2.6 Closing the server
8.2.6.1 Closing the server - floorstand model
Figure 48: Attaching the left-hand side cover
Ê Position the left-hand side cover in such a way that it protrudes approxiate 2
cm at the rear (1). Shut the left-hand side cover.
Ê Push the left-hand side cover all the way forward (2).
Figure 49: Fastening the left-hand side cover
Ê Fasten the left-hand side cover with two screws (1).
Ê Insert the key.
Ê Lock the server.
1
2
1
