TX150 S6 Operating Manual 69
Starting up and operation Controls and indicators
Hard drive activity indicator (green)
An internal drive (HDD) is being accessed.
CSS CSS/Global Error indicator (orange/red)
Generally, the three possible states of this indicator have the
following meanings:
– Does not light up when the system is OK.
– If the event is still acute after a power failure, the indicator is
activated after the restart.
– Lights up when a prefailure event was detected. The indicator
also lights up in standby mode.
– Flashes when an error was detected. The indicator also flashes
in standby mode.
For more details on the indicated errors, you can consult the System
Event Log (SEL), the ServerView Local Service Panel,
ServerView S2 or the ServerView Remote Management via iRMC's
own Web server.
Depending on the color, the states „light up“ and „flash“ have the
following meanings:
– CSS (orange)
Lights up yellow if a prefailure event was detected for a CSS
component.
Flashes orange if an error was detected that you can fix
yourself with the CSS concept (see “Customer Self Service
(CSS)” on page 10).
– Global Error (red)
Lights up red if a prefailure event was detected for a non-CSS
component.
Flashes red if an error was detected for a service incident.
– CSS/Global Error (orange/red)
Lights up and/or flashes alternately orange and/or red if
several prefailure events and/or errors were detected at the
same time (see above).
!
