68 Operating Manual TX150 S6
Controls and indicators Starting up and operation
Controls
Indicators on the control panel
Lock
The server can be locked to prevent access to the drives.
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button. When the system is in operation, it
can be switched off by pressing the On/Off button (standby).
Further information can be found under “Other On/Off options” on
page 77.
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug.
NMI NMI button
I Do not press! The NMI button may only be used by service
personnel.
RST reset button
Pressing the reset button reboots the system.
ID ID button
When the ID button is pressed, the ID indicators (blue) on the
front and rear of the server light up synchronously.
Power/standby indicator (green/orange)
Lights up green when the server is switched on and ready.
Lights up orange when the server is connected to the mains
voltage, but is switched off (standby mode).
