Fujitsu primergy TX150 - Standard Operations; Sliding the Drive Cover

31
PRIMERGY TX150 S4 User’s Guide
1
Overview
1.4 Standard Operations
This section explains such standard operations as turning the server on/off and
inserting/ejecting CD-ROMs.
1.4.1 Sliding the Drive Cover
1 Turn the drive cover key counterclockwise to unlock the cover.
2 Slide the drive cover.
Slide the drive cover down to use the floppy disk drive, CD-ROM drive, or a 5-inch internal
option device.
Drive cover key
Drive cover
