Using a Proxy Server for the Internet Connection (iX1600 /
iX1500)
Configure the Internet connection via a proxy server.
The setting for using a proxy server can be configured when [Access point connection] is selected
for [Wi-Fi connect mode].
1. Press
in the home screen on the touch panel of the ScanSnap to
display the [Settings] screen.
2. Press
to display the [Wi-Fi settings] screen.
3. Press [Access point connection] to display the [Access point connection]
screen.
4. Press [Proxy Server] to display the [Proxy Server] screen.
5. Turn on [Use of Proxy Server].
6. Press the input field for [Host Name/IP address], enter the host name or the
IP address, and press [OK].
7. Press the input field for [Port Number], enter the port number, and press
[OK].
8. When the proxy server requires authentication, turn on [Authentication] and
perform the following operations.
1. Press the input field for [User name], enter the user name and press [OK].
2. Press the input field for [Password], enter the password, and press [OK].
9. Press
to return to the home screen.
Access Point Connect Settings (iX1600 / iX1500)
168

Table of Contents

Other manuals for Fujitsu ScanSnap iX1600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap iX1600 and is the answer not in the manual?

Fujitsu ScanSnap iX1600 Specifications

General IconGeneral
LetterYes
Card thickness (max)0.76 mm
ISO A-series sizes (A0...A9)A3, A4, A5
ISO B-series sizes (B0...B9)B4, B5, B6
Scanning media types supportedBusiness Card, Post Card(JPN)
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight0 - 80 g/m²
Maximum scan size216 x 360 mm
ADF scan speed (b/w, A4)600 ppm
Optical scanning resolution600 x 600 DPI
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-B
Input voltage100 - 240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Quantity per pack1 pc(s)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
DisplayTFT
Scanner typeADF + Manual feed scanner
Product colorBlack
Display diagonal4.3 \
Sensor typeColour CIS
Scan driversISIS, ScanSnap, TWAIN
Scan file formatsJPG, PDF
Daily duty cycle (max)- pages
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
CertificationCE, RoHS
Standard input capacity50 sheets
Sustainability certificatesENERGY STAR, RoHS
Weight and Dimensions IconWeight and Dimensions
Depth161 mm
Width292 mm
Height152 mm
Weight3400 g
