How to Place Documents (SV600)
When you place down documents, use the Background Pad.
If you scan documents without using the Background Pad, the document edges may not be detected
correctly and the created scanned image may be different from the document.
For details about documents that can be scanned with the ScanSnap, refer to "Documents to Scan
(SV600)" (page 271).
l "Scan Area" (page 272)
l "When Placing a Standard Size Document" (page 273)
l "When Placing a Book" (page 273)
l "When Placing Multiple Documents at Once" (page 273)
Scan Area
Place documents with the scanned side face-up in the following scan area.
Use the following to determine the scan area.
l Area: Reference marks of the Background Pad
l Height: Lines on the base of the ScanSnap
30 mm (1.18 in.)
Line
5 mm (0.2 in.)
300 mm (11.81 in.)
400 mm
432 mm
(15.75 in.)
(17.01 in.)
ATTENTION
If a document is placed outside of the scan area, part of the scanned image may be left out or blurred.
Scanning Documents with SV600
272
