Fujitsu ScanSnap iX1600 User Manual

Scanning Documents of Different Widths or Lengths in One Batch
(iX1600 / iX1500 / iX1400)
Documents of different widths or lengths can be scanned in one batch.
For details about documents that can be scanned, refer to "Documents to Scan (iX1600 / iX1500 /
iX1400)" (page 181).
1. Open the ADF paper chute (cover) of the ScanSnap.
ADF Paper Chute (Cover)
Example: iX1600
a For iX1600/iX1500, the touch panel is activated.
For iX1400, the [Scan] button flashes in blue. The button returns to being lit normally when
document scanning is enabled.
In addition, the ScanSnap Manager icon in the notification area located at the far right of
the taskbar changes from
to .
2. Pull out the extension and the stacker on the ADF paper chute (cover).
Extension
Stacker
Scanning Documents with iX1600 / iX1500 / iX1400
194

Fujitsu ScanSnap iX1600 Specifications

General

Letter	Yes
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Quantity per pack	1 pc(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	Black
Display diagonal	4.3 \
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, RoHS
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
