Fujitsu ScanSnap iX1600 User Manual

Extension
Stacker
Example: iX1600
3. Attach the Receipt Guide.
For details, refer to "Attaching the Receipt Guide (iX1600 / iX1500 / iX1400)" (page 111).
4. Load documents in the ADF paper chute (cover).
Load documents in the guides on the Receipt Guide according to the width of each guide.
Load the documents face-down and top-first with their back facing you.
Example: iX1600
5. Start scanning.
For iX1600/iX1500, press the [Scan] button in the home screen on the touch panel.
For iX1400, press the [Scan] button on the ScanSnap.
ATTENTION
Do not perform the following operations during scanning. Doing so will stop scanning.
l Connect or disconnect the ScanSnap and other USB devices.
l Close the ADF paper chute (cover).
l Change user accounts on the computer
l Allow the computer to enter sleep mode.
Scanning Documents with iX1600 / iX1500 / iX1400
200

Fujitsu ScanSnap iX1600 Specifications

General

Letter	Yes
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Quantity per pack	1 pc(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	Black
Display diagonal	4.3 \
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, RoHS
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
