Fujitsu ScanSnap iX1600 User Manual

Side Guide
ATTENTION
When the [Place document face up] checkbox is selected in the [Scanning mode option] window,
load the documents face-up and bottom edge down.
To open the [Scanning mode option] window, click the [Option] button in the [Scanning] tab of the
"ScanSnap Setup Window" (page 89).
7. Adjust the side guides to the width of the documents.
Hold each side guide in the middle to adjust them. Otherwise, the documents may be fed
skewed.
Documents
8. Press the [Scan] button on the ScanSnap to start a scan.
ATTENTION
Do not perform the following operations during scanning. Doing so will stop scanning.
l Connect or disconnect the ScanSnap and other USB devices.
Scanning Documents with S1300i
303

Fujitsu ScanSnap iX1600 Specifications

General

Letter	Yes
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Quantity per pack	1 pc(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	Black
Display diagonal	4.3 \
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, RoHS
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
