Fujitsu ScanSnap iX1600 User Manual

No. Name Description
3 Top cover Open it to remove jammed documents or clean the inside of the
ScanSnap.
For details about how to clean the inside of the ScanSnap, refer to
"Cleaning the Inside of S1100i" (page 462).
4 [Scan/Stop] button Press this button to start or finish scanning.
Indicates the status of the ScanSnap as follows:
Blue (lit): Ready
Blue (flashing): Scanning
Orange (flashing): Error
5 Feeding section Insert the document here to load.
Side
6
7
No. Name Description
6 Tape seal Remove this tape seal after installing the software.
7 USB connector Used to connect a USB cable.
Parts and Functions
82

Fujitsu ScanSnap iX1600 Specifications

General

Letter	Yes
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Quantity per pack	1 pc(s)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	Black
Display diagonal	4.3 \
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, RoHS
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
