Appendix
Recovery and Utility tools
Note: Recovery and Utility tools may not be available on your system depending
on the region from which the system was shipped.
Diagnostics tool: The Diagnostics tool is designed f or use by IT pro fessionals. It is not like ly you
will need to use this tool. If you should need to use this tool, perform the following steps:
1. Press the Diagnostics Tool button to start the Diagnostics tool.
2. R ead the note, and then click OK.
3. C hoose one or more of the following options for diagnostics on the Fujitsu Hardw are Diagnostics
Tool window: CPU, Memory, Display, Hard Disk, CD/DV D/BD, Floppy Disk, Keyboard, and Mouse.
4. Click the Option button in the Tool menu to specify how many times the tool
should run diagnostics on each selected compone nt.
5. Press Execute to start the D iag nostics to ol.
6. Afte r the execution is completed, the selected components are circled in red to indicate that they
have been diagnosed and the result dialog window opens. Click Close to close the window.
7. Click End to close the Diagnostics tool, and then click Yes to confirm the end of diagnostics session.
Recovery too l: The Recovery tool contains two options:
• Restore C Drive: Restore recovery image (only C: drive)
• Restore Full Hard Drive: Rest ore recovery image (full hard drive).
You can use these tools to r estore the Recovery Image from the h idden partition, an d p erform a full
hard drive recovery. Please refer to instructions above for details on how to create a Recovery Image.
Restore the Re
covery Image from Hidden Partition
1. Click [Restore C: drive] from Recovery a nd Utility tools
2. The progress
bar is followed by “Restore Recovery image (only C: drive)” screen
confirming t
hat the Image will be restored to the C: drive. Click Next.
3. R ead the instruction screen and select Agree, then click Next.
4. Click OK to
acknowledge the wa rning message to restore recovery image to the C: drive.
5. W hen the progress bar app ears, wait for the process to c omplete.
6. Click Fin
ish when the process completes; the computer will restart to Windows.
7. F ollow the steps listed in the “Auto Installation support for software packages
from hidden partition” section.
8. D ownloa
d FSDM (Fujitsu Software Download Manager) from the support site and download
all the
software applicable to the model an d OS u sing FSDM.
9. F ollow the steps listed in “Auto Installation support for software packages
downloaded from support w ebsite” section.
100 Fujitsu
