FULTON RBC1250 - 3.3 Boiler Control Panel Functions

RB-RBC-IOMM-2015-1
Fulton Ltd
Page 18
OPERATION - 3
Figure. 14 - Boiler Control Box
Note: Components and their location on the control box will vary with boiler specication.
3.2.3 BOILER CONTROL PANEL
RWF40 PID
controller
BT1050 Boiler
blowdown timer
(iftted)
Pressure gauge
PM5 test
Lowrehold
Flame failure reset
Pump select
Modulating
pressure
transducer
Gas pilot
Gas main
Ignition
High water
High limit pressure
switch
Power on isolator
switch
LC3050
level limiters
(iftted)
Pump on/off
Pump & burner/
pump only
Audible alarms
2nd low water reset
High pressure reset
Burner on
Power on
Gas pressure
1st low water
Flame failure
LC2250 level
controller(iftted)
BC3150 Blowdown
controller(iftted)
