RB-RBC-IOMM-2015-1
Fulton Ltd
Page 58
APPENDIX - A
Probe Lengths - RB Series
Fulton Ltd
Dimensions mm
Dimensions are approximate and only intended as a guide to aid installation.
Technical Information
Sheet No. 136 Issue 1
Every effort is made to ensure accuracy at time of going to press. However as part of our policy of continual product improvement, we reserve the right to alter specications without prior notice.
TI136 11 14 ISSUE 1
Telephone: +44 (0) 117 972 3322
Fax: +44 (0) 117 972 3358
E-mail: sales@fulton.co.uk
Website: www.fulton.co.uk
Fulton Ltd
5 Fernhurst Road, Fishponds, Bristol, BS5 7FG, England.
FM 28400
003
MODEL: RB SERIES 1600 2600 3400
Pump OFF 475 535 510
Pump ON 495 555 530
1st. Low Water 565 625 600
2nd. Low Water 580 640 615
High Water 400 460 435
1st. Low Water
2nd. Low Water
Pump On
Pump Off
30mm
minimum
20mm
180mm
15mm 70mm
2nd. Low Water 1st. Low Water
Pump On
High Water
Pump Off
Normal Working
Level (NWL)
