FULTON RBC1250 - Section 1 - Introduction; General; Product Overview; Technical Data

RB-RBC-IOMM-2015-1
Fulton Ltd
Page 1
INTRODUCTION - 1
SECTION 1 - INTRODUCTION
1.1 GENERAL
TheFultonRBandRBCSeriesfuelredsteamboilerservicemanualisagenericpublication,
providing information on standard boiler operation and maintenance.
Every care has been taken in the manufacture of the boiler to ensure that quality and reliability
standards are maintained. Satisfactory performance can only be ensured if the installation
recommendations, operating routines and maintenance schedules laid out in this manual are
adhered to.
1.3 TECHNICAL DATA
Forafullspecicationreferto:
RB
Appendix A - TI-135-RB Dimensions & Specication.
RBC
Appendix A - TI-109-RBC Dimensions & Specication.
1.2 PRODUCT OVERVIEW
TheFultonRBandRBCseriessteamboilersareconventional,reverse-red,three-pass,
wet-back boiler with an optional internal economiser constructed to BS 2790 1992.
The RB uses a naming system that refers to steam output.
The RBC uses a naming system that refers to kW rating.
The boiler is mounted on a skid frame and is equipped with control and combustion equipment
accordingtoindividualspecications.Thecontrolandcombustionequipmentcanbettedon
either side of the boiler to suit the installation.
Theboileristtedwithfrontandrearaccessdoorstothecombustionzonesforcleaningand
maintenance purposes. Waterside access is via a manhole in the crown of the boiler, while hand/
head holes are provided in the lower boiler shell to facilitate inspection. The optional economiser
isannedtubeheatexchangermountedintherearsmokeboxoftheboiler.
Boilercombustionisprovidedbygas,oilordualfuelredburnersdesignedforhigh/lowame
operation.Combustionairisnormallycontrolledbyamotorisedbutterydamperincorporatinga
proof of closure interlock.
Burnercontrolsandafuelpumpunit(oil-redmodelsonly)aremountedontheburner.
Note: Consult burner manufacturer’s Operation and Maintenance instructions for more details.
