APPENDIX - A
TI135 ISSUE 1
Speci cation
Everyeffortismadetoensureaccuracyattimeofgoingtopress.Howeveraspartofourpolicyofcontinualproductimprovement,wereservetherighttoalterspecicationswithoutpriornotice.
TI135 11 14 ISSUE 1
Telephone: +44 (0) 117 972 3322
Fax: +44 (0) 117 972 3358
E-mail: sales@fulton.co.uk
Website: www.fulton.co.uk
Fulton Ltd
5 Fernhurst Road, Fishponds, Bristol, BS5 7FG, England.
FM 28400
003
MODEL: RB UNIT 1600 2600 3400
S P S P S P
CE marked to PED, EMC, LVD & Machinery Directive, constructed to BS2790 as standard
(othercodespecicationsavailable).
General
Steam Output F & A 100°C kg/h 1150 1600 1900 2600 2800 3400
kW Rating kW 750 1100 1250 1700 1850 2250
Operating Pressure barg 10.34 10.34 10.34 10.34 10.34 10.34
Weight
Shipping Weight (ex. burner) kg 4750 4800 7300 7350 8900 8950
Operational Weight kg 6200 6250 9585 9635 11790 11840
Water Content L 1450 1450 2285 2285 2890 2890
Ef ciencies
Gross % 91 91 91 91 91 91
Net % 82 82 82 82 82 82
Gas Pressures
Min. Natural Gas Modulating mbar 15.7 52.2 45.7 49.7 66.4 66.6
Min. Natural Gas On/Off mbar 15.7 52.2 45.7 49.7 66.4 66.6
Max. Natural Gas mbar 150 150 150 150 150 150
Firing Rate ****
Gas m
3
/h 89 123 146 200 215 262
Oil L/h 72 100 119 163 175 213
LPG/Propane m
3
/h 32 44 52 71 77 93
Ventilation Requirements for Combustion Purposes (Free Area)
Low Level Inlet cm
2
4020 5770 6520 8770 9520 11520
High Level Outlet cm
2
2010 2885 3260 4385 4760 5760
Electrical Requirements
FLC 400 V 3 ph 50 Hz A/ph 16 16 19 19 21 21
Burner Fan, Light Oil Fired kW 2.2 2.2 2.2 2.2 5.5 5.5
Burner Fan, Gas Fired kW 2.2 2.2 4 4 4.5 4.5
Burner Fan, Dual Fuel kW 2.2 2.2 4 4 4.4 4.4
Feedwater Pump kW 2.2 2.2 2.2 2.2 3 3
Connection Sizes
All threads BSP. All  anges to BS4504, PN16-A2 unless otherwise stated.
Steam Outlet (PN16) DN 65 65 100 100 100 100
Safety Valve Discharge (PN16) DN 40 40 50 50 65 65
Feedwater Inlet (PN16) DN 25 25 32 32 32 32
Feedwater Pump Inlet (BSP) DN 25 25 - - - -
Feedwater Pump Inlet (PN16) DN - - 32 32 32 32
Blowdown, Boiler (PN16) DN 25 25 32 32 32 32
Blowdown, Water Level Gauge
(Sight Glass) (BSP)
DN 15 15 15 15 15 15
Blowdown, TDS (PN16) DN 25 25 25 25 25 25
Flue Outlet in. 300 300 350 350 450 450
Water Sample Outlet (PN16) DN 15 15 15 15 15 15
Gas Inlet, natural gas (BSPP) DN 40 40 40 40 - -
Gas Inlet, natural gas (PN16) DN - - - - 80 80
Oil Connection in. Flexible hoses provided 1/2 in. BSP all models.
Note:
**** Figures based on gross cv  gures from DUKES report 2010.
***** Gas booster not  tted.
