Equipment Menu (Item) Pass word/key point Note
System settings;
(CH preset, Mode selection, etc)
Jumper connection and
press S17 on PANEL
board.
ATIS setting JP-1: SUB-CPU board.
CH70 setting JP-2: SUB-CPU board.
FM-7000
Setting to connect DSC JP-2: PANEL board
JP-2: SUB-CPU board.
FM-7500 Refer to DSC-5 and FM-7000
FM-8000 System settings menu.
Turn the power on while
pressing and holding the
[CH16] key, enter to
“652111”.
System settings menu.
Turn the power on while
pressing and holding the
[RCL] key, select the
system CH 9999, then
press the [RCL] “1562”
and [ENT] key.
Channel presetting
CH 1 to 200
To erase CH;
[RCL] [0] [ENT]
Power adjustment
[ENT]+[8]:HI power
[ENT]+[9]:LOW power
[ENT]+[7]:TUNE power
System CH 9998 “0”.
Self test (Transceiver unit)
Turn the power on while
pressing and holding the
[TX] key.
Set the RF gain VR
maximum.
FS-1562
Self test (LCD/key/Ver)
Turn the power on while
pressing and holding the
[ENT] key.
System settings menu.
Turn the power on while
pressing and holding the
[RCL] key, select the
system CH 9999, then
press the [CH] “75” and
[ENT] key.
Channel presetting
Each band; 0,1,2,4,6 ---25
To erase CH;
[Freq.] [0] [ENT]
Power adjustment
[ENT]+[8]:HI power
[ENT]+[9]:LOW power
[ENT]+[7]:TUNE power
System CH 9998 “0”.
Self test (Transceiver unit)
Turn the power on while
pressing and holding the
[CURSOL] key.
Set the RF gain VR
maximum.
FS-75/2550
Self test (LCD/key/Ver)
Turn the power on while
pressing and holding the
[ENT] key.
