110
6 Modifications to the basic vehicle
6.12 Handling of EV system
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
6.12.2 High voltage shutoff and reset
(a) Safety precautions for bodywork
Bodywork requires safety measures such as
shutting off the high voltage. Performing the work
without shutting off the high voltage may cause an
electric shock or damage to the equipment.
Shut off the high voltage depending on the content
of the bodywork as follows:
• Work that requires the shutoff of the high voltage
• Bodywork
Example: Bodywork including support frames
for flat bed, box, damp, etc.
12 V tail gate lifter bodywork
• Replacement of high voltage parts
• Disassembly/assembly of suspension and
brake parts or work under the cab
• Vehicle demonstration at exhibitions
Work
allowed
or not
Work items
Simple
shutoff *
High
voltage
shutoff
Caution
Yes
General
Welding
E E
The distance to the high voltage harness
and cover shall be 500 mm or greater.
Machining
E E
The distance to the high voltage harness
and cover shall be 500 mm or greater.
Painting
E E
The high voltage parts and harnesses
shall not be painted.
Assembly of
non-high
voltage parts
E E
Equal potential bonding of the high
voltage parts shall not be disassembled
(into black and yellow cables).
Electric/
electronic
Soldering
E E
-
High voltage
parts
Installation/
removal
E E
These parts shall not be accessed by any
worker other than specialized in the
servicing of high voltage parts.
Body Assembly
E E
-
No
General
work
E E
No one is allowed to touch or move the
high voltage parts (including umber
cables) or to tow the vehicle (at the
vehicle speed of 20 km/h or higher) with
the Ready indicator in the meter panel off.
*Shut off the high voltage by pressing the high voltage shutoff switch
X
X
X
X
X
X
X
X
