6 Modifications to the basic vehicle
6.12 Handling of EV system
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
User nameCompany/branch name
Worker name/dateWork codeVehicle identification number
Travel distanceModel nameRegistration date㻾㼑㼓㼕㼟㼠㼞㼍㼠㼕㼛㼚㻌㼚㼡㼙㼎㼑㼞
Check the following items and enter the appropriate values.
Check the Duspol high voltage tester appearance and function for abnormalities.A1
Inspection date of the Duspol high voltage tester
The vehicle wheels are locked with chocks.
The sign of “High voltage vehicle. Danger: high voltage” is raised.
Turn off the starter switch. Remove the starter key and store it in a safe place.
The charge connector is removed.
The high voltage shutoff switch is pressed in.
Inspection of the high voltage related parts: Check the high voltage battery appearance for abnormalities.
A2
V1
V2
V3
V4
V5
V6
.
Remove the protection cover and blind plug from the high voltage battery,
and securely install the high voltage break out box on the high voltage battery.
Securely install the blind plug to the high voltage break out box.
V6
The high voltage shutoff switch is released.
The READY lamp is lit when the starter switch is turned on with the shift lever in the P position.
Energisation of the high voltage battery (measurement via the high voltage break out box)
T1
T2
M1
䚷
The voltage measured in M1 is DC 250V or higher.
Turn off the starter key and store it in a safe place.
Press in the high voltage shutoff switch.
Remove the connection to the 12V battery.
Wait for 5 minutes or longer.
M2
L1
L2
L3
L4
Proceed to the second page
Voltage Shutoff Work Report: eCanter
㻴㻴㼂㻗
㼂
㻴㼂㻙
Time
Time
1/2
