Check the following items based on the content of the work performed and enter the necessary values.
I1 Check the insulation resistance tester appearance and function for abnormalities.
I2
Measuring status of the insulation resistance
(Measurement via the high voltage break out box connected to the high voltage battery box)
Inspection date of the Duspol high voltage tester
I3
The insulation resistance between the high voltage measuring point and the ground is within the
specified range (250 kΩ or higher at 500 V as per the UN Regulation No.100 (ECR-R100) 5.1.3.2).
Check the high voltage equipment for visible damages.
Change the sign from “High voltage vehicle. Shutting off the high voltage” to “High voltage vehicle. Danger: high voltage”
Remove the high voltage break out box from the high voltage battery.
Securely install a blind plug and protection cover to the high voltage battery.
Connect the connection to the 12 V battery.
Release the high voltage shutoff switch.
Turn on the starter switch and wait for the system check.
Remove the sign of “High voltage vehicle. Danger: high voltage” from the vehicle.
Test run (functional check)
Complete the test run (functional check).
Check all the items and enter the numeric values.
I4
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
Travel distance
Travel distance after test run
This vehicle is ready for servicing.
