6 Modifications to the basic vehicle
6.13 Others
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
(c) Do not modify harnesses and connectors of the
SRS air bag system. Do not fix other harnesses
to the air bag or pretensioner harness.
(d) Do not check the SRS air bag circuit using a
multimeter or similar device.
(e) When performing work involving heating to the
cab (e.g. painting), if the temperature becomes
93°C or higher, remove the air bag ECU, sub-G
sensor, air bag module, clock spring, and the
ELR of the seat belt with pretensioner in
advance.
If these parts are to be removed, contact the
department responsible in advance. É 2.1
(f) If the air bag module is removed, place it with
the horn pad upper surface facing up on a flat
site. Do not place any other object on the air
bag module.
(g) Use utmost care when handling the air bag
module, air bag ECU and sub-G sensor. Do not
drop it or subject it to water or oil.
Never apply impact to the air bag ECU and sub-
G sensor, in particular.
Should it be dropped, replace it with a new one
even if it looks all right on the outside.
(h) Do not modify the electrical circuit of the SRS
air bag.
Never use a general-purpose multimeter.
(i) Never source power from the SRS air bag fuse.
(j) Do not turn the clock spring three turns or more
from the neutral position (straight-ahead
position), as a damaged internal harness could
result.
(k) Whenever removing the steering wheel or
steering shaft joint, be sure to place the front
tires in the straight-ahead position, remove the
starter key, and lock the steering wheel.
(l) During reinstallation of the steering wheel,
make sure that the front tires are placed in the
straight-ahead position and the clock spring in
the neutral position.
To bring the clock spring into its neutral
position, follow these steps: turn the clock
spring fully clockwise; turn it counterclockwise
the number of turns specified on the label; and
turn it until the alignment marks are aligned
with each other.
(m)After the work has been completed, use the
SRS air bag warning to check that the system
functions properly.
Turn ON the starter switch and then check that
the SRS air bag warning does not appear
on the meter cluster multi-display.
If the SRS air bag warning appears, consult
an authorized MITSUBISHI FUSO dealer.
