7 Construction of bodies
7.1 General
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
Table of frame stresses (when loaded to rating)
Unit: MPa {kgf/mm
2
}
Material
Condition
High tensile steel plate with tensile strength
SAPH440
440 {45}
HTP540
540 {55}
Vehicles mainly driven on
paved roads
74 {7.5} or less 88 {9.0} or less
Vehicles mainly driven on
rough roads
54 {5.5} or less 64 {6.5} or less
Common
