8.2 Electric wiring
8 Electrics/electronics
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
*: The power supply voltage differs depending upon the vehicle power supply specifications. Refer to "Power
supply voltage" É 8.1.1.
Main load Capacity
F01 10AVCU
F02 10A-
F03 10ASRS airbag
F04* 10AOpt (IGN)
F05 30APower window (driver’s seat side)
10A
Hill start assist system
F06
30APower window (assistant driver’s seat side)F07
20A
-F08
10AMeter cluster, diagnosis connector, combination switchF09
30A
DC/DC converterF10
30A
Blower motorF11
Second display, Cab and spot lampF12
15A
10A
EIS Relay, DC/DC converterF13
10AHorn
F14
10A
F15
20A
Cigarette lighter
Second display
VCU
F16
20A
High voltage battery
F17
10A
ABS ECUF18
Oil pump for motorF19
Hill start assist system ECU, electric vacuum pump, AEBS ECU
F20
15A
10A
10A-
F21
15AMotorF22
10A
-F23
10A
G sensor, shift lever unitF24
10A
Opt (ACC)F25*
10A
Opt (B+)F26*
20A
-F27
15ACharging inlet boxF28
20A
Water pump (HVB 1)F29
20A
Water pump (HVB 2)F30
20A
F31
15A-F34
10A-F33
10AAir-conditionerF32
Fuse
No.
ABS : Anti-lock brake system
AEBS : Advanced emergency brake system
ECU : Electronic control Unit
VCU : Vehicle control unit
SRS : Supplemental restraint system
