5 Damage prevention
5.5 Painting work
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
*3: The Iwata cup:
is a simple paint viscometer, viscocity cup, NK-2 produced by ANEST IWATA Corporation.
For details, please address inquiries to an authorized MITSUBISHI FUSO dealer.
4. Applying the base coat First determine the color of the base repair-painting areas, and then shade
the peripheral areas. Do not apply a thick coat to the base. (12 – 15 µm)
Lightly apply one coat of paint to the areas which the mist of the base coat
(17130 colors) reach (shaded areas).
Promptly proceed to the next process within 2 to 3 minutes (before the paint
becomes touch-dry).
In some cases this process can be omitted.
[Paint blending]
Use the undiluted paint after filtering it. Return the unused paint to its
original container and store it.
If the area to be repair-painted is small, you can carry out shading more
easily by adding a further 10 to 20 % of thinner to reduce the viscosity and
also spraying at a lower air pressure.
Wait for about 7 minutes to allow the paint to set, and then apply clear paint.
[Mixing ratio of paint]
Base coat AC-17130 (quick-drying) 100 (VOLUME)
(When the room temperature is between 10 and 20°C)
Base coat thinner 11070 approx. 70
(16 – 18 seconds by the use of Iwata cup
*3
)
(When the room temperature is between 20 and 25°C)
Base coat thinner 11050 (Standard 20°C)
(When the room temperature is between 25 and 35°C)
Base coat thinner 11040
5. Clear painting Lightly mist-coat all of the areas to be repair-painted, finish continuously
with one wet coat of paint, and then immediately shade the mist area.
[Mixing ratio of paint]
2-liquid type paint Clear 20 – 60 100
2-liquid type paint MS hardner 50
2-liquid type paint Thinner quick-drying Approx. 10
(18 – 20 seconds by the use of Iwata cup
*3
)
[Mixing ratio for ombre painting]
Clear paint blended according to the above 10
2-liquid type paint Thinner For shading 11031 50
* The blended clear paint can be used for up to about 4 hours at normal
temperature.
6. Drying After applying clear paint, wait for 2 to 3 minutes to allow it to set, then
force-dry it at 80°C for 15 minutes.
Process Description of work
