WARNING
Low Battery alarm voltage set Warning normal reset
The T14SG includes an audible alarm that
sounds when the transmitter’s battery voltage drops
below a pre-determined setting; adjustable for cell
types and voltages.
Mixing warning at power ON can be reset to
OFF.
Accessing and Activating the Low Battery
Alarm
1. The Low Battery (LOW BATTERY) alarm
voltage is accessed through the T14SG’s
System Menu. Within the System Menu, use
the SensorTouch™ to highlight the SOUND
option and then press the Return (RTN)
button to conrm the selection.
2. Use the SensorTouch to scroll to the Low
Battery (LOW BATTERY) alarm, and then press
the Return (RTN) button to access the voltage
settings. Using the SensorTouch, adjust the
voltage as desired and/or determined by
the transmitter battery pack being utilized.
The voltage options range from 5.0V to 6.0V.
Suggested voltage settings are as follows:
5-Cell NiCd or NiMH: 5.6V
2-Cell LiFe: 6.0V
Warning normally resetting method
1. Move the cursor to the item you want to
reset to OFF and touch the RTN button to
switch to the data input mode.
2. Select the OFF mode by scrolling the touch
sensor.
*The display blinks.
3. Touch the RTN button. (To terminate the input
and return to the original state, touch the S1
button.)
Warning display:
Airplane: Throttle cut/Idle down/Throttle
position/Snap-roll/Motor position/Airbrake/
Motor
Helicopter: Condition/Throttle cut/Throttle
position/Throttle Hold
Glider: Condition/Motor position/Trim-mix/Motor
● Select [WARNING] in the Linkage menu and
access the setup screen shown below by touching
the RTN button.
● Push S1 button to advance to next page.
Scrolling
● Moving cursor
● Selecting mode
● Adjusting value
● To next page
*About low battery voltage, all the models included in one
transmitter are changed in common. It cannot set to different
voltage for every model. Moreover, data reset is not carried
out.
To Next Page
