FUTABA 14SG S.Bus2 - Switch Setting Method

166
<Appendix>
The various functions used in the T14SG can
be activated by a switch. For the purposes of this
manual, a stick position, VR position, etc. shall be
commonly referred to as a switch in all cases. That
(Switchselectionscreenexample)
When switch is selected
When switch was selected, ON/OFF position
setting is also performed.
*The ON/OFF setting state of each position is displayed.
1.WhenyouwanttochangetheON/OFF
setting,usethetouchsensortomovethe
cursorandtouchtheRTNbuttontoswitch
tothedatainputmode.SwitchtheON/
Offdisplaybyscrollingthetouchsensor.
*ON/OFF display blinks.
3.WhentheRTN button is touched, the
ON/OFFsettingischanged.(TouchtheS1
buttontostopthechange.)
4.Toreturntothepreceedingscreen,move
thecursortothe[ON/OFF]atthetopof
thescreenandtouchtheRTNbutton.
When stick, trim lever, or knob selected
When a stick, trim lever, or knob is used as a
switch, two operation modes can be selected:
1.Whenyouwanttochangethemode,
movethecursorto[MODE]itemand
touchtheRTNbutton toswitchtothe
datainputmode.Switchthedisplay
tothemodeyouwanttochangeby
scrollingthetouchsensorandthenmake
thechangebytouchingtheRTNbutton.
●
Mode:[LIN]/[SYM]
* Set the ON/Off point by the method described on the next page.
Switch selection
1.Usethetouchsensortomovethecursor
(highlights)totheswitchyouwantto
selectandtouchtheRTNbutton.
*The switch blinks.
2.Toreturntothepreceedingscreen,move
thecursortothe[H/WSELECT]atthetop
ofthescreenandtouchtheRTNbutton.
 Or,movethecursortothe[ON/OFF]and
calltheON/OFFpositionsettingscreenby
touchingtheRTNbutton.
Alternate mode setting
 ●ALTERNATE mode:[OFF]/[ON]
1.Movethecursortothe[ALTERNATE]item
andtouchtheRTNbuttontoswitchtothe
datainputmode.
2.Changetothemodeyouwanttosetby
scrollingthetouchsensor.
*The mode display blinks.
3.TouchtheRTNbutton.(TouchtheS1button
tostopthechange.)
4.Toreturntothepreceedingscreen,move
thecursortothe[ON/OFF]atthetopofthe
screenandtouchtheRTNbutton.
Switch Setting Method
Switch selection
When a switch is selected at a mixing function, etc., the selection screen shown below is called.
is, whenever the manual indicates that something is
operated via a switch, it is possible for the user to
activate this setting via a stick, stick position, etc.
