<Functions of Model Menu (Helicopter Functions)>
●Selectthe functionname
andreturntothe Model
menubytouchingthe
RTNbutton. Orthe
HOME/EXIT buttonis
pushed.
<SensorTouch™>
RETURN
THR CURVE/THROTTLE HOVER TRIM
Throttle Curve
Throttle curve function adjusts the throttle
operation curve for each condition to optimize the
engine speed to throttle stick movement.
The Throttle Hover function trims the throttle
near the hovering point. Normally, use it with
hovering conditions. Changes in rotor speed
accompanying changes in the temperature,
humidity, and other flight conditions can be
trimmed. Adjust the throttle so that rotor rotation is
most stable. More precise trimming is also possible
by using this function along with the Hover Pitch
function.
●Select[THRCURVE]attheModelmenu
andaccessthesetupscreenshown
belowbytouchingtheRTNbutton.
*The graph display includes the throttle
hover trim operation.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
(Currently selected condition name)
●Throttlecurvecopy
●curverate
●curvepoint
Normal curve adjustment
*Normal curve creates a basic curve centered around
hovering. Use it along with the normal pitch curve and
adjust so that up/down control results in a constant engine
speed.
Idle up curve adjustment
*Set a idle up curve that maintains a constant speed at all
times, even during operation which reduces the pitch
performed in ight. Create a curve matched to loop, roll,
3D, or other purposes and the idle up curve according to
the performance.
Operation precautions
Warning
When actually starting the engine and flying,
always set the idle up condition switch to OFF
and start the engine at the idle.
[Deleting/returningcurvepoint]
1.Movethecursortothecurvepointsetting
itemyouwanttodelete/returnandtouch
theRTNbuttonforonesecond.
●Throttle curve copy function
 MovetheCOPYitemandtouchtheRTN
buttontoswitch tothedatainputmode.
Selectthecopydestinationconditionby
scrollingthetouchsensorandtouchtheRTN
button.Selectthe[YES]andtouchtheRTN
button.
Setting method
●5-point curve setting
[Curveratesetting]
1.Movethecursortothecurveratesetting
itemyouwantto adjust andtouchtheRTN
buttontoswitchtothedatainputmode.
 Adjusttheratebyscrollingthetouchsensor.
 Initialvalue:P1:0%,P2:25%,P3:50%,P4:75%,
P5:100%
 Adjustmentrange:0%~100%
*When the RTN button is touched for one second, the rate is
reset to the initial value.)
 TouchtheRTNbuttontoendtheadjustment
andreturntothecursormode.
2.Repeatthisprocedureforeachpointas
desired.
[Movingcurvepoint]
1.Movethecursortothecurvepointsetting
itemyouwantto adjust andtouchtheRTN
buttontoswitchtothedatainputmode.
 Adjustthecurvepointbyscrollingthetouch
sensor.
 Initialvalue:P1:(0%),P2:25%,P3:50%,P4:
75%,P5:(100%)
 Adjustmentrange:Upto2.5%infrontofthe
adjoiningpoint
*When the RTN button is touched for one second, the curve
position is reset to the initial value.)
 TouchtheRTNbuttontoendtheadjustment
andreturntothecursormode.
2.
Repeatthisprocedureforeachpointasdesired.
