<Functions of Model Menu (Helicopter Functions)>
●Selectthe functionname
andreturntothe Model
menubytouchingthe
RTNbutton. Orthe
HOME/EXIT buttonis
pushed.
<SensorTouch™>
RETURN
GOVERNOR mixing
When using a Futaba GV-1/GY701/CGY750
governor, this function is used to switch the RPM
of the helicopter's rotor head. The rotor head speed
can be switched with each condition or the switch.
*The governor is used by connecting the governor speed
setting channel to CH7 (initial setting).
*When using an independent governor [ON]/[OFF] switch,
connect the AUX([ON]/[OFF]) connector of the governor to
CH8 and set the switch to CH8 (Governor2) at the Function
menu of the Linkage Menu.
Note: Always set (Control) and (Trim) to [--]
for [Governor] of the Function menu of the
Linkage menu.
●Select[GOVERNOR] attheModelmenuand
accessthesetupscreenshownbelowby
touchingtheRTNbutton.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
(Currently selected condition name)
●Unitdisplayselection:
 [%]/[rpm]
●Setupscreenselection
●ACT/INH:INH(initialsetting)
●FinetuningVRsettings
●RPMadjustment
●Condition/Switchselection
Setting method
●Activate the mixing
 Whenusingthisfunction,movethecursorto
the[INH]itemandtouchtheRTNbuttonto
switchtothedatainputmode.
 SelecttheACTmodebyscrollingthetouch
sensor.
*The display blinks.
 TouchtheRTNbuttontoactivatethemixing
andreturntothecursormode.(ONis
displayed.)
WhentheGovernorischangedfromthe
defaultinhibited(INH)statetotheactive
(ACT)state,theendpointmenuwillbe
displayedandit ispossibletoutilizethe
endpointsforthisgivencondition.
*When the function is set ON/OFF at the governor setup
screen, the governor rpm setting channel end point servo
travel and limit point are now initialized.
*When changed from INH to ACT (ON), the servo travel is
initialized to 100 and the limit point is initialized to 155.
*When operation is changed to INH at all conditions, the
servo travel is initialized to 100 and the limit point is
initialized to 135.
UsetheSensorTouchtoscrolltoeitherYES
(incorporatethedefaultendpoints)orNO
(endpointsarenot utilized.PresstheReturn
(RTN)buttontoconrmtheselectionmade.
●RPM adjustment
 Movethe cursor to the rate item and touch
theRTNbutton toswitchtothedatainput
mode.
 Adjusttherpmbyscrollingthetouchsensor.
 Initialvalue:50%(1500rpm)
 Adjustmentrange:OFF,0~110%(OFF,
700~3500rpm)
*When the RTN button is touched for one second, the
sensitivity is reset to the initial value.)
 TouchtheRTN button to return tothecursor
mode.
●Unit diplay selection
 MovethecursortotheUNITitemandtouch
theRTNbutton toswitchtothedatainput
mode.Selectthe unitbyscrollingthetouch
sensor.
 TouchtheRTN buttontochangethe
operationmodeandreturntothecursor
mode.
