TELEMETRY
Displaying data from the receiver
This screen displays your choice of data from the
receiver.
Also warnings can be activated regarding
other data from your aircraft. For example, if the
receiver voltage drops, the user can be warned by
an alarm (and vibration).
*It cannot be used in FASST mode and S-FHSS mode.
*Only receiver voltage and EXT voltage can be used in
FASSTest12CH mode.
*The FASSTest14CH mode can use all the telemetry functions.
● Select [TELEMETRY] in the Linkage menu and
access the setup screen shown below by touching
the RTN button.
● Push S1 button to advance to next page.
● [TELEMETRY] can be called if the HOME/EXIT button
is pushed from a home screen.
Scrolling
● Moving cursor
● Selecting mode
● Adjusting value
● To next page
● Receiver -> Transmitter. The
reception strength is shown.
How to see telemetry date
1. Telemetry screen can be called if the HOME/
EXIT button is pushed from the home screen.
Or select [TELEMETRY] in the Linkage menu
and access the setup screen by touching
the RTN button.
2. If each item is chosen and the RTN button is
pushed, an alarm setup can be performed
with the minimum/maximum after a
transmitter is turned on.
*Receiver voltage can be checked immediately. An optional
sensor will need to be attached to S.BUS2 of a receiver if
you would like to see other information.
*No special setup is necessary if each sensor displayed
is left as in the default setup. Separate sensor ID
is also unnecessary. However, if two or more of
one kind of sensor is used, setup is required in the
"SENSOR" menu.
Warning
Do not watch the transmitter screen during
ight.
*You may loose sight of the aircraft during ight and this is
extremely dangerous. Have an assistant on hand to check
the screen for you. A pilot should NEVER take his eyes off
his aircraft.
To Next Page
