FUTABA T10PX - Page 106

106
Returntotableofcontents
* The vertical cursor line moves in
conjunction with the operation of
the throttle trigger.
* The vertical cursor line moves in
conjunction with the operation of
the throttle trigger.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Curve rate
-100~+100
Initial value: 0
Point
1~99
Initial value: 50
(Preparation)
-Tap the curve type and select [EXP].
1
Tap the value button of the [EXP rate]. Value
input buttons appear on the screen. When
you want to quicken Throttle operation, use
the [+] button to adjust the + side. When you
want to make Throttle operation milder, use
the [-] button to adjust the - side.
If you tap "Quick" or "Mild" when the value is
other than "0", Quick/Mild is reversed.
2
When finished, return to the Racing menu screen by press-
ing the HOME button twice.
Adjustment method for EXP curve
(Preparation)
-Tap the curve type and select [VTR].
1
Tap the value button of the [VTR rate].
Value input buttons appear on the screen.
When you want to quicken throttle opera-
tion, use the [+] button to adjust the + side.
When you want to make throttle operation
milder, use the [-] button to adjust the - side.
If you tap "Quick" or "Mild" when the value
is other than "0", Quick/Mild is reversed.
2
Curve switching point adjustment
Tap the value button of the [Point]. Value input buttons ap-
pear on the screen, use the [+] or [-] buttons to move to the
point you want to set.
Throttle VTR adjustment
3
When finished, return to the Racing menu screen by pressing the HOME button twice.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Curve rate
-100~+100
Initial value: 0
The throttle EXP, VTR adjustment can be controlled with digital trim DT1 to DT6
or digital dial DL1 etc. with the trim/dial select function. (Linkage menu)
Trim/Dial Setting
RACING MENU
