ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
◆ RegistertheESCwithtransmitter.
◆ TheregisteredESCwillbedisplayedas"FutabaESC".
ConnectSBM-2totheS.I/Fporton
thebackoftransmitter.
◆ Linkagemenu→Sensor→ 3/3
Registrationtotransmitter
● Callpage3of[Sensor].
*Pleasenotethattheproperdefaultslotforthisaccessoryisnumber8(8-15).
Thissensoruseseightslots.Beingmadetoastartslotare8,16,and24.
ConnecttheSBM-2tothe
transmitterasshown,then
tapRegister.
Registrationiscompletewhen
thisscreenappears
Completeregistrationandremove
SBM-2fromthetransmitter.
◆
The registered Hobbywing ESC is displayed as "Hobbywing ESC".
For details on Hobbywing ESC telemetry
support, refer to the Hobbywing website.
Telemetry:FutabaESCMC-980H/A,MC-9130H/A,MC-9200H/A
*FutabaESCmustbeinstalledintheaircraft.

FUTABA T16IZ SUPER Specifications

General

Channels	16
Frequency	2.4GHz
Telemetry	Yes
Voice Alerts	Yes
SD Card Slot	Yes
USB Port	Yes
Trainer Port	Yes
DSC Port	Yes
Modulation	S-FHSS
Battery	2000mAh
Model Memory	30 models
Display	4.3 inch color TFT LCD touch screen
