FUTABA T16IZ SUPER

166
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
GyrosettingGYA553
Config
Config
Select the servo type according to the servo to be
used.
Digital servo → DG : 285 Hz
Analog servo → AN : 70 Hz
The stability of digital-servo mode of a flight
increases in order to perform a high-speed control
action.
Select the SB/R2 port.
Config 1/7 Servo type
Config 1/7 SB/R2OUT
Digital servo Analog servo
S.BUS
S.BUS devices can be
connected to this port.
When using two rudder servos
Rudder 2 Throttle
Headdirectionmark
MODESW
DATASW
MODELED
Aileron
Programbox
S.BUS2
Aileron2
Elevator
Elevator2
Rudder
S.BUS/Rudder2
DATALED
