Viewingthetelemetrydata
Telemetrysystem
＜ Homedisplay ＞
Receivervoltageand
Extvoltagedisplay
This screen displays and sets the various information from the receiver. An alarm and vibration can be
JHQHUDWHGGHSHQGLQJRQWKHLQIRUPDWLRQ)RUH[DPSOHDGURSLQWKHYROWDJHRIWKHUHFHLYHUEDWWHU\KRXVHG
in the aircraft can be reported by an alarm.
● ThisfunctioncanonlybeusedintheFASSTest18CHmodeandT-FHSSmode.TheFASST/S-FHSSmodecannotuse
telemetry.
● FASSTest12CHmode.Applicablewithreceivervoltagedisplay.
● Telemetrysensorssoldseparatelycanbemountedintheaircrafttodisplayavarietyofinformation.(Receivervoltage
doesnotrequireasensor.)
● ThetelemetryfunctioncannotbeusedifthetelemetrymodeoftheparametersisnotACT.
● FASSTest18CH:When2receiversareusedwith1transmitter,thetelemetrycannotbeusedforthe2ndreceiver.
● T-FHSS/FASSTest12CH:When2receiversareusedwith1transmitter,thetelemetryfunctioncannotbeused.
● Ifthetransmitterandreceiverarelinked,butthereceiver'sIDisnotrecordedinthetransmitter'smemory,thetelemetry
functioncannotbeused.
● TurningOFFthereceiverafterusewillcausethetelemetrydatajustpriortothistobedisplayed.(Evenwhenthe
receiver'spoweristurnedOFF,thereceivervoltageisnot0.0V.)
Viewingthereceivervoltage. Settingisunnecessary.Whenmenutelemetry
islistenedto,thevoltageappears.
Viewingthedrivebattery
voltage.
CA-RVIN-700andwiringworkarenecessary.
Usingvariousoptional
telemetrysensors.
Optionaltelemetrysensorsarenecessary.
T16IZSUPERsettingisunnecessary.
Usingseveraltelemetry
sensorsofthesametype.
Settingby"sensor"inthemenuisnecessary.
(Registerisnecessary.)
Settingalarmsfromthe
telemetryinformation.
Settingby"Telemetry"inthemenuis
necessary.
P.93
P.101
P.95
P.97
P.100 〜 121
CAUTION
Donotstareatorsetthetransmitter
settingscreenwhileflying.
■ Losing sight of the aircraft during flight is very
dangerous.
■ When you want to check the information
during flight, call the telemetry screen
before flight and have the screen checked by
someone other than the operator.
Receiver →Transmitter.Thereceptionofthesignal
fromthereceivertothetransmitterisshown.This
doesnotaffectflight.

FUTABA T16IZ SUPER Specifications

General

Channels	16
Frequency	2.4GHz
Telemetry	Yes
Voice Alerts	Yes
SD Card Slot	Yes
USB Port	Yes
Trainer Port	Yes
DSC Port	Yes
Modulation	S-FHSS
Battery	2000mAh
Model Memory	30 models
Display	4.3 inch color TFT LCD touch screen
