VR Programming Guide
August 2022 Page 122 of 144
Field
Description
Transmitter
Mode
Can be set to either “Tx-Disable” or “Tx-Enable”.
TX ON
Does not require user input.
Used to indicated Tx On (checked) or Tx Off (unchecked)
PTT
Offers three settings:
PTT ON VR keys up on selected channel and using programmed setting
(channel type, PL / DPL, NAC etc.)
PTT OFF VR Transmitted is idle
CARRIER VR Transmitter is keyed up with carrier only (no modulation).
Limited to 10 minutes max key up time.
To use PTT ON or CARRIER, the “Test Mode” field must be set to YES
and “Transmitter Mode” must be set to Tx-Enable.
Repeater
CAS
Status
Indicates the Carrier Activated Squelch (CAS) status (Idle or Active) of the VR
RSSI
Indicates the Carrier Activated Squelch (CAS) status of the VR with respect to
the programmed RSSI thresholds on the selected DVR channel.
Sql
Indicates the Carrier Activated Squelch (CAS) status of the VR with respect to
the programmed Squelch thresholds on the selected DVR channel.
RSSI
dBM
Displays the RSSI of the VR in dBM
µV
Displays the RSSI of the VR in µV
PL
Displays presence of the programmed PL / DPL decoded by the VR.
SINAD
Displays the calculated SINAD of the VR received signal.
AVRA/Motion
Input
Displays the state of input as interpreted for AVRA (Active or Inactive) and as
interpreted for Primary/Secondary Preference (Stationary, Motion or N/A)
RF Power
dBm
Displays the VR Tx Power (in dBM) when the VR transmitter is keyed up.
W
Displays the VR Tx Power (in W) when the VR transmitter is keyed up.
Mobile RUS
Indicates when the Mobile radio is receiving a valid signal (Active or Idle).
Mobile PTT
Activated when the MSU MIC is PTT-ed.
Temp
Displays the current controller temperature.
PA_t
Displays the current PA temperature.
Test Mode
Must be set to YES to use the PTT or P25 Rx Modem Test options.
Oper. State
Indicates current VR state Primary, Non-Primary, Permanent Primary or OFF.
Ant. Sw.
Indicates the Antenna switch position; Normal or BL Reversed.
P25 Rx
Modem Test
Test Mode
Set to YES to measure BER
(for test procedure see “BER Test Setup”)
BER
Displays instant Bit Error Rate
BERm
Displays averaged Bit Error Rate
