Futurecom VR - Hardware Setup Window

8G093X01 R5
VR Programming Guide
August 2022 Page 87 of 144
Configuring the Mobile Radio Channel Settings in the VR
Hardware Setup Window
Field Name
Range
Description
Notes
RSSI
OFF
Hysteresis
2 to 20 (5) dB
Sets the RSSI CAS OFF threshold
in dB below the RSSI CAS ON
Threshold (see Repeater Channel
Setup window).
Speed
1 to 10 (5) ms
Sets the RSSI Averaging
Integration Time.
Squelch
ON
Threshold
4 to 28 (16) dB
SINAD
Sets the Squelch ON thresholds.
Affects Analog Mode
only.
OFF
Threshold
3 to 25 (10) dB
SINAD
Sets the Squelch OFF thresholds.
Affects Analog Mode
only.
Speed
10 to 150 (25)
ms
Squelch Averaging Integration
Time.
Reptr. FM
Dev. Limit
12.5kHz
25.0kHz
NPSPAC
0.75 to 2.52
(2.12) kHz
Affects Analog Mode
only.
Depends on the selected
Channel Spacing – refer
to the Frequency Band
Setup.
Note that the
corresponding values for
25kHz channel spacing &
NPSPAC are calculated
based on entry for
12.5kHz
PL FM
Deviation
12.5kHz
25.0kHz
NPSPAC
0.19 to 0.60
(0.38) kHz
Affects Analog Mode
only.
Depends on the selected
Channel Spacing – refer
to the Frequency Band
Setup.
Note that the
corresponding values for
25kHz channel spacing &
NPSPAC are calculated
based on entry for
12.5kHz
PL STE
Delay
120 to 250
(150) ms
PL Squelch Tail Elimination Delay.
Must be set to match the portable
setting.
Affects Analog Mode
only.
If this field is programmed
too short the squelch tail
will not be fully
eliminated. If it is
programmed too long, the
portable may unmute
unnecessarily.
