Personality Data
This section covers the VR channels setup along with the features set required for the various
operation scenarios.
Repeater Channel Setup Window
Field Name
Options / Units
Description
Notes
Ch #
1 to 192
VR Channel Number –
referenced in the Mobile Radio
Channel Setup when
associating VR channels to
Mobile Radio Modes.
Read Only Field.
Name
Seven (7) character
string
VR Channel name (alias)
displayed on the Control Head
when the VR is enabled.
Channel
Mode
F. Duplex
Simplex
Determines the VR mode of
operation for the specific
channel – Full Duplex or
Simplex.
F. Duplex not available for
VRX1000
Fire
Ground
Yes / No
Enables or Disables Fireground
Signalling Capabilities on the
selected VR channel.
Fireground (FG) signaling
can be enabled on analog
or digital VR channels
only.
Channel
Type
Digital
Analog
Mixed
F. Analog
TPS
FA-All
Defines the VR Channel Type.
Mixed Mode is selected when
the same VR channel will be
used by Analog and P25 PSUs.
Rx Freq*
794 to 806 MHz
DVR Rx Frequency
(Must match the PSU Tx
Frequency).
*DVR ONLY field
Rx Frequency is the same
as the programmed Tx
frequency when
programmed in Simplex
mode
Rx PL
[Hz] / DPL
VR Rx PL / DPL
(Must match the Analog PSU
Tx PL / DPL).
Applies to Analog, Mixed
and F. Analog Mode Only.
Tx Freq*
764 to 776 MHz
DVR Tx Frequency
(Must match the PSU Rx
Frequency).
*DVR ONLY field
Splx Freq*
[MHz]
VRX1000 Simplex Rx / Tx
Frequency
(Must match the PSU Rx / Tx
Frequency).
*VRX1000 ONLY field
Tx PL
[Hz] / DPL
VR Tx PL / DPL (Must match
the Analog PSU Rx PL / DPL).
Applies to Analog, Mixed
and F. Analog Mode Only.
PL STE
[deg] / DPL
Analog PSU PL / DPL Squelch
Tail Elimination – must be
programmed to match the PSU.
Applies to Analog, Mixed
and F. Analog Mode Only.
