Maintenance Screens
Two screens are provided for maintenance purposes: Monitoring screen and RSSI setup
screen.
The Configurator’s Monitoring Screen is provided to assist the field technician with VR setup and
troubleshooting.
The VR RSSI Setup screen is provided to assist the users with optimizing the voting algorithm
parameters by creating a typical real-life scenario for VR operation and running some automated
VR tests.
Using the Monitoring Screen
The Futurecom Repeater Configurator Monitoring Screen is provided to assist the field technician
with VR setup and troubleshooting.
The Monitoring screen provides real time indication of the RRSI level, SINAD, RF Power, PL
detection etc. as described below.
IMPORTANT!
It must be noted that the Monitoring screen application is not intended to replace the
use of properly calibrated test equipment in the field.
