Mobile Radio Channel Setup
The VR operation may be enabled on some MSU modes and disabled on others as selected and
programmed in the personality of the MSU interfaced to the VR.
The VR must be ‘made aware’ as to which TGs are ‘DVR Enabled’ and which are ‘DVR Disabled’.
The VR can be used only on the MSU modes listed in the Mobile Radio Channel Setup screen
accessible via Futurecom Repeater Configurator. The Mobile Radio Channel Setup data is
extracted by first exporting the MSU data (using the Motorola CPS) and then importing the data
by using the Import → Motorola XML function of the Futurecom Repeater Configurator as
described in the next paragraph.
Template files (DPD/DCD) are designed to handle a maximum of 2047 entries (comprised of a
combination of channels and zones).
Importing Motorola XML File
Field Name
Range
Description
Notes
Zone #
Read Only
This field is extracted during the “Import →
Motorola File” process.
Ch. #
Read Only
This field is extracted during the “Import →
Motorola File” process.
Name
Read Only
This field shows name
of the corresponding
zone or channel.
- indicates the zone
name when channel #
is "--"
- indicates the channel
name when there is a
valid channel #
displayed
This field is extracted during the “Import →
Motorola File” process.
