DMC-1000 Appendices • 165
J1 Pinout
Pin Block Bit No. SBn,@IN[n] Pin Signal
1 1 7 16 2 Ground
3 1 6 15 4 Ground
5 1 5 14 6 Ground
7 1 4 13 8 Ground
9 1 3 12 10 Ground
11 1 2 11 12 Ground
13 1 1 10 14 Ground
15 1 0 9 16 Ground
17 2 7 24 18 Ground
19 2 6 23 20 Ground
21 2 5 22 22 Ground
23 2 4 21 24 Ground
25 2 3 20 26 Ground
27 2 2 19 28 Ground
29 2 1 18 30 Ground
31 2 0 17 32 Ground
33 3 7 32 34 Ground
35 3 6 31 36 Ground
37 3 5 30 38 Ground
39 3 4 29 40 Ground
41 3 3 28 42 Ground
43 3 2 27 44 Ground
45 3 1 26 46 Ground
47 3 0 25 48 Ground
49 volts 50 Ground
J2 Pinout
Pin Block Bit No. SBn,@IN[n] Pin
1 4 7 40 2 Ground
3 4 6 39 4 Ground
5 4 5 38 6 Ground
7 4 4 37 8 Ground
9 4 3 36 10 Ground
11 4 2 35 12 Ground
13 4 1 34 14 Ground
15 4 0 33 16 Ground
17 5 7 48 18 Ground
19 5 6 47 20 Ground
21 5 5 46 22 Ground
23 5 4 45 24 Ground
25 5 3 44 26 Ground
