166 • Appendices DMC-1000
Pin Block Bit No. SBn,@IN[n] Pin
27 5 2 43 28 Ground
29 5 1 42 30 Ground
31 5 0 41 32 Ground
33 6 7 56 34 Ground
35 6 6 55 36 Ground
37 6 5 54 38 Ground
39 6 4 53 40 Ground
41 6 3 52 42 Ground
43 6 2 51 44 Ground
45 6 1 50 46 Ground
47 6 0 49 48 Ground
49 volts 50 Ground
J3 Pinout (Note: All points are inputs on this cable):
Pin Block Bit No. @IN[n] Pin
1 7 7 64 2 Ground
3 7 6 63 4 Ground
5 7 5 62 6 Ground
7 7 4 61 8 Ground
9 7 3 60 10 Ground
11 7 2 59 12 Ground
13 7 1 58 14 Ground
15 7 0 57 16 Ground
17 8 7 72 18 Ground
19 8 6 71 20 Ground
21 8 5 70 22 Ground
23 8 4 69 24 Ground
25 8 3 68 26 Ground
27 8 2 67 28 Ground
29 8 1 66 30 Ground
31 8 0 65 32 Ground
33 9 7 80 34 Ground
35 9 6 79 36 Ground
37 9 5 78 38 Ground
39 9 4 77 40 Ground
41 9 3 76 42 Ground
43 9 2 75 44 Ground
45 9 1 74 46 Ground
47 9 0 73 48 Ground
49 volts 50 Ground
