A
PPENDIX
A -
Port Functions
Port Menus
DS2000-TS Administrator’s Guide
A - 2
A.1 P
ORT
M
ENUS
Access to the Port Menu is from the Main Menu by selecting <1> Port. The Port Menu is shown in
Figure A-2. The user either selects a port or enters the Port Status menu by pressing <Enter>. The Port
Status menu is shown in Figure A-3. From either the Port Menu or the Port Status menus, the user enters
the port number desired and presses <Enter>. The Functions for Port n (where n is the port number)
appears. All of the port types display the same Functions for Port menu. The Functions for Port n menu is
shown in Figure A-4. Selecting the Virtual Pad port (10) shows only a configuration menu.
Figure A-2. Port Menu
The Port Status menu provides an overview of each port on the DS2000-TS. The display shown when Port
Status is selected is shown in Figure A-3. The display provides the Port Number, Name, Protocol, State, and
Status of each port in the DS2000-TS. The information is a snapshot of the port status when Port Status is
selected and is updated every minute or by pressing the <Enter> key. Table A -1 provides a description of
the information provided in the Port Status menu.
*** Port Menu ***
Port Name
E0 Ethernet S13 SERIAL-S13 S29 SERIAL-S29
S0 Sync/Async S14 SERIAL-S14 S30 SERIAL-S30
CON Console S15 SERIAL-S15 S31 SERIAL-S31
10 Virtual PAD S16 SERIAL-S16 S32 SERIAL-S32
S1 SERIAL-S1 S17 SERIAL-S17
S2 SERIAL-S2 S18 SERIAL-S18
S3 SERIAL-S3 S19 SERIAL-S19
S4 SERIAL-S4 S20 SERIAL-S20
S5 SERIAL-S5 S21 SERIAL-S21
S6 SERIAL-S6 S22 SERIAL-S22
S7 SERIAL-S7 S23 SERIAL-S23
S8 SERIAL-S8 S24 SERIAL-S24
S9 SERIAL-S9 S25 SERIAL-S25
S10 SERIAL-S10 S26 SERIAL-S26
S11 SERIAL-S11 S27 SERIAL-S27
S12 SERIAL-S12 S28 SERIAL-S28
_________[DynaStar_6b2c]__________
Press ESC to return to previous menu Press <RET> for port status
