A
PPENDIX
A -
Port Functions
Configuration
DS2000-TS Administrator’s Guide
A - 6
.
** Note: For IP routing to be active, IP addresses must be assigned. Other restrictions may also apply to IP
routing. See Appendix B,
“Network Commands”
for IP Router configuration options.
A.2.2
A
sync Port Configuration
The Async Port Configuration menu is accessed from the Port menu by typing in <S1 - S32> and then
selecting <1> Configuration. The Async Port Configuration menu is shown in Figure A-6 and the
parameters are described in Table A-3. An advanced menu is also available to set additional parameters for
the Async port. This menu is accessed from the Async Port Configuration menu by pressing <CTRL-O>
and is shown in Figure A-7 and described in Tab le A-4.
Table A-2. Ethernet Interface Parameters
Parameter Definition Default Range
Port The physical port. E0 On-board
Ethernet
N/A
Port Name The name of the port. Ethernet 14
alphanumeric
characters
MAC Address The MAC address. The MAC
address of the
DS2000-TS
N/A
IP routing IP parameter allows this port to participate with the internal
IP router. The internal Router can be used to support remote
IP access to the Console system or to route IP packets
between Ethernet ports.
YY (Yes)
** enabled
N (No)
LAN Speed Speed for copper 10/100 Mbps interfaces
100 Mbps for SFP ports
Auto Negotiate 10 Mb/s
100 Mb/s
Auto Negotiate
