JF-240UV User Manual
130
GCC JF-240UV Flatbed (VLCD) Description
OPEN
Enable JF-240UV calibration online connection
CLOSE
Disable JF-240UV calibration online connection
IP ADDRESS
IP address
SAVE
Save IP address settings
Color Offset
Configure print direction, unidirectional indicates printing image from right to
left, bidirectional indicates image will be printed from right to left, then left to
right. This setting is to establish the unidirectional / bidirectional precision.
Uni direction Offset
Print the unidirectional alignment
calibration pattern chart for print head
parameter tuning.
Bi direction Offset
Print the bidirectional alignment
calibration pattern chart for print head
parameter tuning.
Print Settings
VWKCMY
Open/Close print head channel
UV lamp curing mode
Normal Curing
Delay Curing
UV Power
UV power adjustment
0~100
Print Speed Level
Print speed adjustment
Level 1~5
Enable Static bar
Enable the static bar
Enable job repeat
function
Set number of job repeats 1~999
Enable compensate color offset by print head gap
Enable job repeat
function with roll
media
Set number of job repeats when printing
on roll media with roll to roll system
1~999
Distances between two jobs
Max.: 500mm
Negative Pressure
Reset to Zero
Reset negative pressure to 0 kap
Set kpa
Negative pressure settings
Check engine board
version
Read engine board version
Job Ink Use
VWKCMY /CC/Price/L
Check ink consumption and print time of
a file
PH PARAMETERS
Ink jet print head parameter settings
Channel
K、C、M、Y、V、W ink jet head color name
