Chapter 3: Operating instructions
TruVision DVR 10 User Manual 15
Item Name Description
9 MENU Switches from live mode to menu mode and displays the main
menu.
10 Ç, È, Å, Æ (arrow buttons)
OK (central button)
In menu mode, the Left or Right Arrow buttons select
commands or options; the Up or Down Arrow buttons edit or
select values. OK enters the selection or value.
PTZ direction control.
Playback speed control.
11 Lens control FOCUS and ZOOM control for camera lens.
12 SRCH Displays the Search screen to search for and play back
recorded video.
13 REC Displays the Manual Record screen.
14 DISP Displays multiscreen. Switches to live mode.
15 LIVE Displays Camera 1 in live mode.
To place batteries into the IR remote control:
1. Remove the battery cover.
2. Insert the batteries. Make sure that the positive (+) and negative (−) poles are
correctly placed.
3. Replace the battery cover.
To connect the remote control to the TVR 10:
1. Turn on the TVR 10 and wait for the live video to appear.
2. On the remote control, press and release the Power button. The remote control is
now operational.
To turn off the IR remote control:
1. Press the TVR 10 button while the IR remote control is still controlling the TVR 10.
To turn the TVR 10 off with the remote control:
1. Press and hold the POWER button for several seconds. A power off prompt
displays.
2. Enter a password, if required.
3. Select Confirm then switch off the manual power located on the back panel.
Troubleshooting the remote control
If the IR remote control is not functioning properly, perform the following tests:
