Chapter 3. Programming
44 PanaFlow™ LC User’s Manual
Table 5: Analog Output Error Handling with Path Error Handling set to ON
Ch1 in Error Ch2 in Error Ch3 in Error
Error displayed in
Meter
Expected
Composite
Volumetric(Act)
behavior
Analog Output
Response
No No No No Error Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
Yes No No E22:
SingleChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
No Yes No E22:
SingleChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
No No Yes E22:
SingleChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
Yes Yes No E23:
MultiChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
No Yes Yes E23:
MultiChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
Yes No Yes E23:
MultiChAccuracy
Measured
Composite
Volumetric(Act)
mA proportional to the
Measured Composite
Volumetric(Act)
Yes Yes Yes E23:
MultiChAccuracy
Measured
Composite
Volumetric(Act)
will hold the last
good value
mA value based on the
[Error Handling]
setting
