PanaFlow™ LC User’s Manual 85
Chapter 4. Error Codes and Troubleshooting
4.9 Transmitter Errors
These errors are from the Transmitter subsystem. Should you encounter one of the Transmitter Errors,
follow recommended actions as indicated in Table 26 and contact BHGE factory.
Table 26: Transmitter Error Description and Recommended Actions
4.10 Option I/O Errors
Table 27: Option I/O Errors Description
Error Code Error Message Description / Recommended Action
X1: MCU RAM Error Transmitter RAM Fail Memory test on transmitter RAM failed. Try
power cycling the meter. If error persists after
power cycle, contact BHGE factory
X2: MCU Flash CRC
Error
Flash memory test failed Flash memory test failed. Try power cycling the
meter. If error persists after power cycle, contact
BHGE factory
X7: MPU not Detected No flow board detected Flow board is not detected by the transmitter.
Try power cycling the meter. If error persists
after power cycle, contact BHGE factory
X12: System Command
Fail
System command failed System command failed. Try power cycling the
meter. If error persists after power cycle, contact
BHGE factory
X13: Get GUI Node Fail Failed to generate GUI Failed to generate GUI. Try power cycling the
meter. If error persists after power cycle, contact
BHGE factory
X14: Node Memory Fail GUI node memory failed GUI node memory failed. Try power cycling the
meter. If error persists after power cycle, contact
BHGE factory
X15: Font API Initialize
Fail
Failed to generate font Failed to generate font. Try power cycling the
meter. If error persists after power cycle, contact
BHGE factory
X16: XML File Initialize
Fail
XML file initialization failed XML file initialization failed. Try power cycling
the meter. If error persists after power cycle,
contact BHGE factory
Error Code Error Message Description
A1:AnalogCh(S2:3)
Error!
ADC Channel(S2:3) is not
responding
Analog input /RTD input is not working. If error
persists after power cycle, contact BHGE factory
A2:AnalogCh (S2:4)
Error!
ADC Channel(S2:4) is not
responding
Analog input /RTD is not working. If error
persists after power cycle, contact BHGE factory
A3:AnalogCh (S2:1)
Error!
DAQ Channel (S2:1) is not
responding
Analog output (4-20mA) is not working. If error
persists after power cycle, contact BHGE factory
A4:AnalogCh (S2:2)
Error!
DAQ Channel (S2:2) is not
responding
Analog output (4-20mA) is not working. If error
persists after power cycle, contact BHGE factory
