GE C70

D-2 C70 CAPACITOR BANK PROTECTION AND CONTROL SYSTEM – INSTRUCTION MANUAL
REVISION HISTORY APPENDIX D: MISCELLANEOUS
D
Table D-2: Major changes for C70 manual version AF2 (English)
Table D-3: Major changes for C70 manual version AF1 (English)
1601-9015-X2 6.0x 5 April 2012 12-3254
1601-9015-Y1 7.0x 30 September 2012 12-3529
1601-9015-Y2 7.0x 11 November 2012 12-3601
1601-9015-Z1 7.1x 30 March 2013 13-0126
1601-9015-AA1 7.2x 1 August 2013 13-0401
1601-9015-AB1 7.3x 7 November 2014 14-1408
1601-9015-AB2 7.3x 1 September 2015 15-2215
1601-9015-AC1 7.40x 8 December 2016 16-3319
1601-9015-AE1 7.41x 31 January 2017 17-3427
1601-9015-AE3 7.4x 28 April 2017 17-3561
1601-9015-AF1 7.6x 30 June 2017 17-3779
1601-9015-AF2 7.6x 31 October 2017 17-3935
Page Description
--- General revision
--- Added type W CPU module to order codes in chapter 2, installation chapter 3, Replace Front Panel section in chapter 10
--- Added Japanese and Polish languages and modules 6W and 6X to order codes in chapter 2. Module 6W allows 30 contact
inputs, and Module 6X allows 18 outputs.
3-17 Added contact input and contact output modules 6W and 6X to Table 3-3 Contact Input and Output Module Assignments and
to Figure 3-17 Contact Input and Output Module Wiring (Sheet 3 of 3)
5-289 Updated Thermal Overload Protection Logic diagram
Page Description
--- General revision
--- Updated "faceplate" to "front panel" for consistency and to reflect web site
--- Added graphical front panel option to order codes and specifications in chapter 2, Interfaces chapter 4, Settings chapter 5,
Actual Values chapter 6
--- Added PEAP-GTC and PAP protocols for authenticating user logins when using a RADIUS server. Added to Settings > Product
Setup > Security > RADIUS Authentication Method and to Modbus memory map and F codes.
--- Updated Contact Inputs from 96 to 120 and Contact Outputs from 64 to 72 in Product Description in chapter 2 and FlexLogic
operands table in chapter 5
--- Updated Neutral Time Overcurrent number from 3 to 6 in FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Phase Instantaneous Overcurrent number from 6 to 12 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Phase Time Overcurrent number from 3 to 6 in FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Neutral Instantaneous Overcurrent number from 6 to 12 in FlexLogic operands table, settings, features per product
table, Modbus memory map
3-67 Added Connect to a D400 Gateway section
4-43 Updated LED Labelling instructions for the new Front Panel Label Designer
4-50 Added Standard Front Panel section for labelling LEDs and pushbuttons
5-105 Added USB Port section to enable/disable the USB port on the graphical front panel
5-119 Updated User-programmable Pushbuttons section as per specifications
5-140 Updated Breakers section as per specifications
5-146 Updated Disconnect Switches section as per specifications
Manual P/N C70 revision Release date ECO
